Specifications

Technical Specifications of Elastic Waste Shredder DS3003
Model	DS4005
Feed Width	400 mm
Voltage	415 volts AC 3 phase 50 Hz
Power Required	5 HP
Shred Capacity	50 kgs to 100 kgs/hr
Shred Size	12mm x 60mm (uneven)
Duty Cycle	Continuous – non-stop running, no cooling required
Applications	This is used to shred elastic waste such as elastic straps, elastic belts, elastic jeans, elastic trousers.

Salient Features

User-friendly and durable machine.
Installation and maintenance services on site.
Control Panel with auto reverse and anti-jamming feature, 360-degree safety with LOTO switch.
3-phase indicator lamps with stop, start, and reverse inching push buttons.
All guards interlocked with limit switch (at extra cost).
Run time – Continuous duty.
Easy to clean & lubricate.
Overload & phase failure protection.
No plastic parts used in manufacturing. All metal parts with rugged construction.
Vibration free.
Separate movable trolley is provided to collect the output.
Large waste collection trolley for collecting large volumes of output.

FAQs

FAQs related to Shredder Machines

Q. What material can I shred in the shredder?

A. Papers, Monocartons, Blister foil, Aluminium foil, Vouchers, Corrugated box, X-ray films, Outsters,

Credit cards, Debit cards, Lottery tickets, Label stock, Blister packs with medicines, Confidential papers, Computer printouts, Cheque leaflets, Sim cards, Pharma waste, Plastic waste, FRP Waste, Wood Waste, etc.

Q. What does “Throat Width” or "Feed Width" mean?

A. Feed Width or Throat width refers to the size of the opening in which you put your materials. For maximum efficiency and speed, its best to choose a width that will comfortably accommodate the material you want to shred most.

Q. How do I maintain my Shredder or Grinder?

A. The most common things to cause shredder problem is user misuse and abuse, including overloading it. Proper training on the use of shredders can help minimize these problems. The other major component to keeping your shredder working properly is keeping the cutting head properly oiled. Depending on the type of shredder you purchase, this will vary. Oil lubricates the cutting blades, extending their life and helping them run smoother and quieter.
